Mega-Lite MW1 LED Moving Head Wash Light with Pixel Control
28 in stock
Additional information
| Owner | Aaron Salinas LLC |
|---|
Product Details
The MW1 is part of the M-Series. This compact unit is equipped with seven 40W RGBW OSRAM LEDs that can be individually controlled for easy pixel control. With versatile uses it can be used as a wash or beam. It features a 9° beam angle that can project sharp beams when needed and a 44° wash angle that creates a soft-edge wash effect. Featuring powerful stepper motors that allow the unit to create fast and slow movements, it has a 540° pan and 270° tilt. The MW1 can be used in numerous applications such as church, theater, mobile DJ and clubs to add alluring multi-colored effects.
PDF Downloads:
Additional Information
What’s Included
- MW1: ITEM# 1215
- 12V Fan: ITEM# 1180-FAN-12V
- 19V Fan: ITEM# 1180-FAN-19V
- Display PCB: ITEM# 1215-PCB-DIS
- Power Supply: ITEM# 1215-POW
- Pan Band: ITEM# 1215-BAN-PAN
- Tilt Band: ITEM# 1215-BAN-TIL
- DMX Connections: ITEM# 1215-CON-DMX
- LED Replacement: ITEM# 1215-LED
- LED Driver Board: ITEM# 1215-PCB-DRI
- Quick Release Mount: ITEM# 1210-HOU-QUI
Specs
- DMX Connectors: 5 & 3 Pin XLR Connectors In & Out
- Power Connection: PowerCon Type In and Out
- Display: LCD Display
- Shutter: Electronic Shutter
- Strobe: 18 Flash/Second
- Pan: 540° 8/16-bit 3 Phase Motors
- Tilt: 270° 8/16-bit 3 Phase Motors
- Pan & Tilt Lock: Yes
- Power Supply: 100V-240 50/60 Hz
- Power Consumption: 376 Watts / 3.24 Amps
- Fastening System: 2 Quick Release B-Directional Clamp Mounts
- Thermal: Max Ambient Temperature 110° Max Surface Temperature 140° Max Operating Temperature 104°
- LED Quantity: 7
- LED Type: 40W OSRAM
- Ballast: Electronic Auto Switching
- Protocol: DMX 512
- DMX Channels: 39 Channel Mode
